- Up to 16 channel IP cameras can be connected
- Supports decoding H.265+/H.265/H.264+/H.264 video formats
- Up to 8-ch @ 1080p decoding capacity
- 1 HDMI and 1 VGA interfaces: both interfaces support independent video output
- 4 HDDs for continuous video recording
- Plug & Play with 16 Power-over-Ethernet(PoE) interfaces
- Supports various specific function cameras, including thermal camera /fisheye/people counting/heatmap/ANPR (automatic number plate recognition)
- Channel-zero function ensures smooth remote live view and playback in low bandwidth environments
Call for Price
Specification
Description
|
Video and Audio
|
|
IP Video Input
|
16-ch
|
|
Incoming Bandwidth
|
160 Mbps
|
|
Outgoing Bandwidth
|
160 Mbps
|
|
HDMI Output
|
4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
|
|
VGA Output
|
1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
|
|
Audio Output
|
1-ch, RCA (Linear, 1 KΩ)
|
|
Two-Way Audio
|
1-ch, RCA (2.0 Vp-p, 1kΩ)
|
|
Decoding
|
|
Decoding Format
|
H.265/ H.265+/H.264/H.264+/MPEG4
|
|
Recording Resolution
|
8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA/4CIF/DCIF /2CIF/CIF/QCIF
|
|
Synchronous playback
|
16-ch
|
|
Decoding Capability
|
2-ch @ 8 MP (25fps) / 4-ch @ 4MP (30fps) / 8-ch @ 1080p (30fps)
|
Network
|
Network Protocol
|
TCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP™, HTTPS
|
|
Network Interface
|
1 RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
|
|
PoE
|
|
Interface
|
16, RJ-45 10/100 Mbps self-adaptive Ethernet interface
|
|
Power
|
≤ 200 W
|
|
Standard
|
IEEE 802.3 af/at
|
Auxiliary Interface
|
Serial Interface
|
1 RS-485 (half-duplex), 1 RS-232, 1 keyboard (optional)
|
|
SATA
|
4 SATA interfaces
|
|
Capacity
|
Up to 6 TB capacity for each HDD
|
|
Alarm In/Out
|
16/4
|
|
USB Interface
|
Front panel: 2 × USB 2.0; Rear panel: 1 × USB 3.0
|
|
General
|
|
Power Supply
|
100 to 240 VAC, 50 to 60Hz, 1 A
|
|
Consumption
|
≤ 20 W (without enabling PoE and HDD)
|
|
Working Temperature
|
-10 °C to 55 °C (14 °F to 131 °F)
|
|
Working Humidity
|
10 to 90 %
|
|
Dimension (W × D × H)
|
445 × 400 × 71 mm ( 17.5″× 15.7″ × 2.8″)
|
|
≤ 5 kg (11. lb, without HDD)
|
Data Sheet
User Manual
Qucik Start Guide
| Category | Line | Default Warranty Period(Month) |
|---|---|---|
| Analog cameras | Analog cameras | 24 |
| DVR | 7 Series DVR | 24 |
| 89 Series DVR | 36 | |
| Board | 24 | |
| DVS | DVS | 24 |
| Hilook | Hilook | 12 |
| IP cameras (IPC) | 1 Series IPC | 12 |
| 2 Series IPC | 24 | |
| 4/5/7/8 Series IPC | 36 | |
| 6 series IPC | 36 | |
| Zoom camera/zoom camera module | 36 | |
| Speed dome | AE/DE Series speed dome | 24 |
| AF/DF Series speed dome | 36 | |
| PTZ | 36 | |
| Anti-corrosion/anti-explosion | 36 | |
| Thermal imaging | Thermal imaging | 36 |
| NVR | 7 Series NVR | 24 |
| 89 Series NVR | 36 | |
| Hilook | Hilook | 12 |
| Large screen | LCD | 12 |
| LED | 12 | |
| DLP | 12 | |
| Displayer (≤24 inches) | 12 | |
| Displayer (>24 inches) | 12 | |
| Interactive display | 12 | |
| Information release screen | 12 | |
| Control | Integrated platform | 24 |
| Decoder | 36 | |
| Video wall controller | 36 | |
| Transmission | Optical transceiver/switch | 24 |
| Transmission cable | 60 | |
| All-in-one server | Blazer | 36 |
| Storage | SAN | 36 |
| Data center | Data center | 24 |
| Universal server | 36 | |
| Intelligent transportation system | Traffic cameras | 24 |
| Supplement light and auxiliary | 24 | |
| Traffic server | 24 | |
| Signal control | 24 | |
| RFID | 24 | |
| Mobile | Mobile | 24 |
| Portable terminal | PVR system | 24 |
| Portable speed dome | 24 | |
| Body camera | 24 | |
| Others | 24 | |
| Entrance & exit | Entrance & exit | 24 |
| Parking lot | 24 | |
| Access control | Access controller | 24 |
| Access control terminal | 24 | |
| Card reader | 24 | |
| Card issuer /card enrollment station | 24 | |
| Access Portal | 12 | |
| Lock | Smart lock | 12 |
| Intercom | Video intercom | 24 |
| Alarm | Emergency alarm | 24 |
| Auto-alarm（excluding Pyronix） | 36 | |
| Consumer storage device – portable storage | M100 Series | 12 |
| Portable T100 Series | 36 | |
| Consumer storage device – NAS | W100 Series | 12 |
| H100 Series | Device: 24
HDD/SSD: 36 |
|
| Consumer SSD | E100, E100N/E1000N Series | 36 or SSD lifespan, whichever occurs first. |
| Enterprise SSD | S100, S200 Series | 36 or SSD lifespan, whichever occurs first. |
| Surveillance SSD | V100/V200 Series | 36 or SSD lifespan, whichever occurs first. |
| Consumer memory card | E1/E10 Series | 84 or memory card lifespan, whichever occurs first. |
| Surveillance memory card | H1, L1/L2, H10 Series | 24 or memory card lifespan, whichever occurs first. |
| EZVIZ | All Series | 12 Months |
