- High quality imaging with 2 MP resolution
- Excellent low-light performance
- Efficient H.265+ compression technology
- Water and dust resistant (IP67)
- 24/7 colorful imaging
Call for Price
SKU: DS-2CD1027G0-L
Categories: All Products, IP ColorVu, Network Cameras
Tag: Hikvision IP ColorVu Camera
Specification
Description
|
Camera
|
|
Image Sensor
|
1/2.8″ Progressive Scan CMOS
|
|
Max. Resolution
|
1920 × 1080
|
|
Min. Illumination
|
Color: 0.001 Lux @ (F1.0, AGC ON)
|
|
Shutter Time
|
1/3 s to 1/100,000 s
|
|
Angle Adjustment
|
Pan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360°
|
|
Lens
|
|
Lens Type & FOV
|
2.8 mm, horizontal FOV 107, vertical FOV 56, diagonal FOV 127 4 mm, horizontal FOV 84, vertical FOV 45, diagonal FOV 99
|
|
Focal Length & FOV
|
2.8mm, horizontal FOV 107°, vertical FOV 56°, diagonal FOV 127° 4mm, horizontal FOV 84°, vertical FOV 45°, diagonal FOV 99°
|
|
Lens Mount
|
M12
|
|
Iris Type
|
Fixed
|
|
Aperture
|
F1.0
|
|
Depth of Field
|
2.8 mm: 1.7 m to ∞ 4 mm: 2.1 m to ∞
|
|
Lens Type
|
Fixed focal lens, 2.8 and 4 mm optional
|
Illuminator
|
Supplement Light Type
|
White Light
|
|
Supplement Light Range
|
Up to 30 m
|
|
Smart Supplement Light
|
Yes
|
|
Video
|
|
Main Stream
|
50 Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720) 60 Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720)
|
|
Sub-Stream
|
50 Hz: 25fps (640 × 480, 640 × 360, 320 × 240) 60 Hz: 30fps (640 × 480, 640 × 360, 320 × 240)
|
|
Video Compression
|
Main stream: H.265+/H.265/H.264+/H.264 Sub-stream: H.265/H.264/MJPEG
|
|
Video Bit Rate
|
32 Kbps to 8 Mbps
|
|
H.264 Type
|
BaseLine Profile/Main Profile/High Profile
|
|
H.265 Type
|
Main Profile
|
|
Region of Interest (ROI)
|
1 fixed region for main stream
|
|
Network
|
|
Protocols
|
TCP/IP, ICMP, HTTP, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, QoS, IPv6, UDP, Bonjour, SSL/TLS
|
|
Simultaneous Live View
|
Up to 6 channels
|
|
API
|
ONVIF (PROFILE S, PROFILE G), ISAPI, SDK
|
|
User/Host
|
Up to 32 users. 3 user levels: administrator, operator and user
|
|
Security
|
Password protection, complicated password, HTTPS encryption, IP address filter, security audit log, basic and digest authentication for HTTP/HTTPS, TLS 1.2, WSSE and digest authentication for ONVIF
|
|
Client
|
iVMS-4200, Hik-Connect, Hik-Central
|
|
Web Browser
|
Plug-in required live view: IE8, IE9, IE10, IE11 Local service: Chrome 57.0+, Firefox 52.0+
|
|
Image Settings
|
Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser
|
|
Day/Night Switch
|
Day, Night, Auto, Schedule
|
|
Wide Dynamic Range (WDR)
|
Digital WDR
|
|
Image Enhancement
|
BLC, HLC, 3D DNR
|
Interface
|
Ethernet Interface
|
1 RJ45 10M/100M self-adaptive Ethernet port
|
|
Event
|
|
Basic Event
|
Motion detection, exception (illegal login)
|
|
Linkage
|
Upload to FTP/NAS, notify surveillance center, send email, trigger recording, trigger capture *Note: External device is required.
|
General
|
Power
|
12 VDC ± 25%, 0.30 A, max. 3.6 W, Ø5.5 mm coaxial power plug, reverse polarity protection PoE: 802.3af, Type 1 Class 3, 36 V to 57 V, 0.20 A to 0.10 A, max. 4.5W
|
|
Dimension
|
68.4 × 65.2 × 161.1 mm (2.7″ × 2.6″ × 6.3″)
|
|
Package Dimension
|
172 × 104 × 80 mm (6.8″ × 4.1″ × 3.1″)
|
|
Approx. 420 g (0.9 lb.)
|
|
|
With Package Weight
|
Approx. 510g (1.1 lb.)
|
|
Storage Conditions
|
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
|
|
Startup and Operating Conditions
|
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
|
|
Language
|
English
|
|
General Function
|
Anti-flicker, heartbeat, mirror, privacy masks, flash log, password reset via e-mail, pixel counter
|
Approval
|
EMC
|
FCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC (ICES-003: Issue 6, 2016); KC (KN 32: 2015, KN 35: 2015)
|
|
Safety
|
UL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013); CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013); BIS (IS 13252(Part 1):2010+A1:2013+A2:2015)
|
|
Environment
|
CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)
|
|
Protection
|
Ingression protection: IP67 (IEC 60529-2013)
|
User Manual
Qucik Start Guide
SpecIcons
| Category | Line | Default Warranty Period(Month) |
|---|---|---|
| Analog cameras | Analog cameras | 24 |
| DVR | 7 Series DVR | 24 |
| 89 Series DVR | 36 | |
| Board | 24 | |
| DVS | DVS | 24 |
| Hilook | Hilook | 12 |
| IP cameras (IPC) | 1 Series IPC | 12 |
| 2 Series IPC | 24 | |
| 4/5/7/8 Series IPC | 36 | |
| 6 series IPC | 36 | |
| Zoom camera/zoom camera module | 36 | |
| Speed dome | AE/DE Series speed dome | 24 |
| AF/DF Series speed dome | 36 | |
| PTZ | 36 | |
| Anti-corrosion/anti-explosion | 36 | |
| Thermal imaging | Thermal imaging | 36 |
| NVR | 7 Series NVR | 24 |
| 89 Series NVR | 36 | |
| Hilook | Hilook | 12 |
| Large screen | LCD | 12 |
| LED | 12 | |
| DLP | 12 | |
| Displayer (≤24 inches) | 12 | |
| Displayer (>24 inches) | 12 | |
| Interactive display | 12 | |
| Information release screen | 12 | |
| Control | Integrated platform | 24 |
| Decoder | 36 | |
| Video wall controller | 36 | |
| Transmission | Optical transceiver/switch | 24 |
| Transmission cable | 60 | |
| All-in-one server | Blazer | 36 |
| Storage | SAN | 36 |
| Data center | Data center | 24 |
| Universal server | 36 | |
| Intelligent transportation system | Traffic cameras | 24 |
| Supplement light and auxiliary | 24 | |
| Traffic server | 24 | |
| Signal control | 24 | |
| RFID | 24 | |
| Mobile | Mobile | 24 |
| Portable terminal | PVR system | 24 |
| Portable speed dome | 24 | |
| Body camera | 24 | |
| Others | 24 | |
| Entrance & exit | Entrance & exit | 24 |
| Parking lot | 24 | |
| Access control | Access controller | 24 |
| Access control terminal | 24 | |
| Card reader | 24 | |
| Card issuer /card enrollment station | 24 | |
| Access Portal | 12 | |
| Lock | Smart lock | 12 |
| Intercom | Video intercom | 24 |
| Alarm | Emergency alarm | 24 |
| Auto-alarm（excluding Pyronix） | 36 | |
| Consumer storage device – portable storage | M100 Series | 12 |
| Portable T100 Series | 36 | |
| Consumer storage device – NAS | W100 Series | 12 |
| H100 Series | Device: 24
HDD/SSD: 36 |
|
| Consumer SSD | E100, E100N/E1000N Series | 36 or SSD lifespan, whichever occurs first. |
| Enterprise SSD | S100, S200 Series | 36 or SSD lifespan, whichever occurs first. |
| Surveillance SSD | V100/V200 Series | 36 or SSD lifespan, whichever occurs first. |
| Consumer memory card | E1/E10 Series | 84 or memory card lifespan, whichever occurs first. |
| Surveillance memory card | H1, L1/L2, H10 Series | 24 or memory card lifespan, whichever occurs first. |
| EZVIZ | All Series | 12 Months |
