- High quality imaging with 4 MP resolution
- 24/7 full color imaging
- Efficient H.265+ compression technology
- Clear imaging against strong back light due to 120 dB WDR technology
- Water and dust resistant (IP67)
- Robust structure design with full metal materials
Call for Price
SKU: DS-2CD2047G1-L
Categories: All Products, IP ColorVu, Network Cameras
Tag: Hikvision IP ColorVu Camera
Specification
Description
|
Camera
|
|
Image Sensor
|
1/1.8″ progressive scan CMOS
|
|
Min. Illumination
|
Color: 0.0014Lux @ (F1.0, AGC ON), 0 Lux with white light
|
|
Shutter Speed
|
1/3 s to 1/100,000 s
|
|
Slow Shutter
|
Yes
|
|
Wide Dynamic Range
|
120dB
|
|
Angle Adjustment
|
Pan: 0 to 360°, tilt: 0 to 90°, rotation: 0 to 360°
|
|
Lens
|
|
Focus
|
Fixed
|
|
Lens Type
|
2.8/4/6 mm
|
|
FOV
|
2.8 mm, horizontal FOV: 102°, vertical FOV: 51°, diagonal FOV: 125° 4 mm, horizontal FOV: 89°, vertical FOV: 46°, diagonal FOV: 105° 6 mm, horizontal FOV: 54°, vertical FOV: 30°, diagonal FOV: 62°
|
|
Aperture
|
F1.0
|
|
Lens Mount
|
M16
|
|
Aperture Type
|
Fixed
|
|
Illuminator
|
|
White Light Range
|
30m
|
|
Video
|
|
Max. Resolution
|
2560 × 1440
|
|
Main Stream
|
50Hz: 25fps (2560 × 1440, 2304 × 1296, 1920 × 1080, 1280 × 720) 60Hz: 24fps (2560 × 1440), 30fps(2304 × 1296, 1920 × 1080, 1280 × 720)
|
|
Sub Stream
|
50Hz: 25fps (640 × 480, 640 × 360, 320 × 240) 60Hz: 30fps (640 × 480, 640 × 360, 320 × 240)
|
|
Video Compression
|
Main stream: H.265+/H.264+/H.265/H.264 Sub-stream: H.265/H.264/MJPEG
|
|
Video Bit Rate
|
32 Kbps to 8 Mbps
|
|
H.264 Type
|
Baseline Profile/Main Profile/High Profile
|
|
H.265 Type
|
Main Profile
|
|
H.264+
|
Main stream supports
|
|
H.265+
|
Main stream supports
|
|
Scalable Video Coding (SVC)
|
Yes
|
|
Region of Interest (ROI)
|
Support 1 fixed region for main stream
|
|
Network
|
|
Simultaneous Live View
|
Up to 6 channels
|
|
API
|
ONVIF (PROFILE S, PROFILE G), ISAPI, SDK
|
|
Protocols
|
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS
|
|
User/Host
|
Up to 32 users,3 levels: Administrator, Operator and User
|
|
Network Storage
|
Support micro SD/SDHC/SDXC card (128 G) local storage, NAS (NFS,SMB/CIFS), ANR
|
|
Client
|
iVMS-4200, Hik-Connect, Hik-Central
|
|
Web Browser
|
IE8+, Chrome41.0-44, Firefox30.0-51, Safari8.0-11
|
|
|
|
Day/Night Switch
|
Day/Night
|
|
DNR
|
3D DNR
|
|
Image Enhancement
|
BLC/3D DNR/HLC
|
|
Image Settings
|
Saturation, brightness, contrast, sharpness, AGC, and white balance are adjustable by client software or web browser
|
Interface
|
On-board Storage
|
Built-in micro SD/SDHC/SDXC slot, up to 128 GB
|
|
Hardware Reset
|
Yes
|
|
Communication Interface
|
1 RJ45 10M/100M self-adaptive Ethernet port
|
|
Event
|
|
Smart Event
|
Line crossing detection, intrusion detection
|
|
General
|
|
Web Client Language
|
English, Russian, Italian, French, Polish, Portuguese, Spanish, Turkish
|
|
General Function
|
One-key reset, anti-flicker, heartbeat, mirror, password protection, privacy masks, IP address conflict, flash log
|
|
Storage Conditions
|
-30 °C to 60 °C (-22 °F to 140 °F)
|
|
Startup and Operating Conditions
|
-30 °C to 60 °C (-22 °F to 140 °F)
|
|
Power Supply
|
12 VDC ± 20%, PoE: 802.3af
|
|
Power Consumption and Current
|
12VDC, 0.5 A, max. 6 W; PoE:(802.3af, 36V to 57V), 0.2 A to 0.1 A, max. 7.5 W
|
|
Camera Dimension
|
85 × 85 × 218 mm (3.3″ × 3.3″ × 8.6″)
|
|
Package Dimension
|
315 × 137 × 141 mm (12.4″ × 5.4″ × 5.6″)
|
|
Camera Weight
|
0.710 kg (1.6 lb.)
|
|
With Package Weight
|
1.035 kg (2.3 lb.)
|
Approval
|
Protection
|
IP67
|
